1. Core display advantages (COB high-definition image quality)
Technology core: Flip-chip COB LED (high pixel density, delicate picture, no graininess at close range)
Pixel configuration: 1.5mm pitch (P1.5 level) (high-definition imaging, accurate detail restoration, suitable for indoor close viewing)
Brightness/contrast: 600cd/㎡ + ≥7000:1 (indoor environment is clear and non-glaring, dark field details are outstanding)
Wide viewing angle: horizontal 160° + vertical 160° (multi-person viewing in multi-person scenes without color cast, suitable for conference rooms/control centers)
Color performance: 14-bit grayscale + 4.39 trillion display colors, color uniformity ≤±0.003Cx, Cy (color is accurate and without deviation, restoring the real picture)
Fluency: 3840Hz refresh rate + 60Hz frame rate (dynamic pictures without flicker, video/data display is smooth)
Color temperature adjustment: 3000K-10000K adjustable (matching different indoor scene lights, flexible adaptation to style)
2. Structure and maintenance (convenient and worry-free)
Cabinet configuration: Die-cast aluminum cabinet (sturdy structure, impact resistance, suitable for long-term indoor use)
Protection level: IP54 (dust-proof and moisture-proof, reducing the impact of indoor dust and slight moisture on the screen)
Maintenance method: front maintenance design (no need to dismantle the screen, direct frontal maintenance/part replacement, reducing maintenance difficulty and downtime)
Advantages of integration: ready to use out of the box (eliminating complex assembly steps, high installation efficiency, suitable for quick implementation projects)
3. Stability and energy saving (low consumption and durability)
Power supply adaptation: 110~220V AC±15% (common to global indoor projects, no additional power modification required, adaptable to multiple regions)
Power consumption control: average ≤240W/㎡ (low energy consumption, low electricity cost for long-term use), maximum ≤750W/㎡ (stable operation under high load)
Durability: Lamp beads have a lifespan of 100,000 hours (long-term use does not require frequent replacement, reducing later maintenance costs)
4. Environmental adaptation (compatible with multiple scenarios)
Working environment: temperature – 15℃~50℃, humidity 10%~90% RH (non-condensation) (covers most indoor environments, no fear of air conditioning temperature difference / normal humidity)
Storage environment: temperature – 40℃~80℃, humidity 10%~90% RH (no condensation) (not easily damaged during transportation and storage)
5. Core adaptation scenarios
Accurate matching: corporate conference rooms, data control centers, exhibition hall display areas, education and training classrooms, high-end retail stores
Integrated Design + COB HD Display – Perfect for Professional Indoor Environments
Featuring 1.5mm pixel pitch with COB technology, the display delivers ultra-fine, dot-free visuals. With 600cd/㎡ brightness and ≥7000:1 contrast, even dark details remain crisp. The 14-bit grayscale and 4.39 trillion colors ensure precise color reproduction with uniformity ≤±0.003 Cx,Cy, while 160° horizontal and vertical viewing angles provide consistent visuals from multiple perspectives.
A 3840Hz high refresh rate guarantees smooth, flicker-free motion, and adjustable color temperature from 3000K to 10000K allows seamless adaptation to meeting rooms, control centers, and other professional spaces.
Constructed with die-cast aluminum cabinets, the display is robust and reliable. IP54 protection ensures dust and moisture resistance, and front-access maintenance enables easy servicing without disassembly.
The display supports 110–220V wide voltage, with average power consumption ≤240W/㎡, making it energy-efficient. It operates in temperatures from -15℃ to 50℃ and 10–90% non-condensing humidity, suitable for most indoor environments. With 100,000-hour LED lifespan and integrated, plug-and-play design, installation is fast and hassle-free.
